Specifications
- Brand: Stihl
- Power : 6 hp
- Weight (Approx.) : 30 kg
- Fuel Used : Petrol
- Displacement : 212 cc
- Stroke : 4
- Model No. :┬аWP 600
- Automation Grade : Semi-Automatic
- Inlet Size : 3 inch (7.62 cm)
- Outlet Size : 3 inch (7.62 cm)
- Max. Output Power : 1050/min
- Max. Suction Height : 7 meter
- Max. Flow Capacity : 63 m3/h
- Max. Pumping Height : 31 m
- Oil Consumption :┬а 1 Litre/Hr
- Speed : 3600 RPM
- Tank Capacity :┬а3.6 L
- Starting System :┬а Recoil Starter
- Max. Delivery :┬а 31 Mtr
- Motor type : EHC 605.0
Description
Features┬а:
- Anti Vibration System : FOR EXCELLENT VIBRATION DAMPING. Vibration dampers mounted in a straight line on the motor and on the flange of the pump housing reduce mechanical stresses on the entire device and ensure smooth running, even at high motor speeds.
- Stihl EHC Engine :┬аPOWERFUL AND RELIABLE. STIHL water pumps are equipped with powerful and reliable STIHL EHC 4-stroke petrol engines.
- Strong Frame :┬аFOR GOOD STABILITY. The robust frame ensures good stability of the STIHL water pumps on different surfaces and at the same time protects the engine from damage.
Applications┬а:
- Use┬а For a Wide Range of Water Conveying Tasks In Agriculture & Designed for Pumping Water from a Variety of Sources, Including Ponds, Lakes, and Rivers
Usage┬а:
- Fill the tank with unleaded petrol
- Attach the suction hose to the pump's intake and the delivery hose to the outlet.
- Ensure all connections are secure and leak-free.
- You prime the pump by filling it with water through the priming plug. This removes air and prepares it to draw water effectively
- Ensure the fuel valve is open, allowing petrol to flow to the engine. If the engine is cold, engage the choke.
- Pull the recoil starter cord gently until you feel resistance, then give it a sharp tug.
- Repeat until the engine starts.
- Once the engine starts, gradually disengage the choke as it warms up.
- Adjust the throttle to control the water flow rate
